Description
NIHONWELD SUGARHARD 90 is a premium spray-type hardfacing electrode engineered for demanding sugar mill roller maintenance and resurfacing applications. Designed with an aggressive spray arc and excellent penetration capability, this electrode allows efficient application even while the mill is in operation.
The electrode deposits a highly abrasion-resistant and corrosion-resistant hardfacing layer that improves the grip of crushing rollers on sugar cane. This enhanced traction increases the quantity of sugar cane processed, leading to higher extraction efficiency and improved sugar production.
SUGARHARD 90 is ideal for extending the operational life of sugar mill rollers while minimizing maintenance downtime in heavy-duty industrial environments.
Key Features
- Spray-type hardfacing electrode
- Aggressive arc with excellent penetration
- Suitable for in-operation mill applications
- Improves grip and crushing efficiency
- High abrasion resistance
- Corrosion-resistant weld deposits
- Enhances sugar extraction performance
- Long-lasting hardfacing protection
Classification
- DIN 8555: E10-UM-65-G
Typical Chemical Composition of Weld Metal Deposits (%)
| C | Si | Mn | Cr |
|---|---|---|---|
| 3.50 | 1.20 | 2.60 | 29.00 |
Hardness of Weld Metal
| Hardness Type | Value |
|---|---|
| Vickers (Hv) | 700 – 750 |
| Rockwell (HRC) | 60 – 62 |
Size and Recommended Current Range (DC+)
| Diameter | Length | Current Range |
|---|---|---|
| 3.2 mm | 450 mm | 120 – 170A |
| 4.0 mm | 450 mm | 160 – 220A |
| 5.0 mm | 450 mm | 180 – 240A |
Welding Positions
- Flat
- Fillet
- Horizontal
Applications
- Sugar mill roller hardfacing
- Roller resurfacing and maintenance
- Abrasion-resistant industrial applications
- Sugar cane crushing equipment
- Corrosion and wear protection
- Heavy-duty maintenance operations
