Description
Gemini 7018LT — Product Information & Qualifications
Gemini 7018LT is a premium low-hydrogen stick electrode designed for smooth, stable arc performance in every welding position. Engineered for fabrication, repair, and structural work, it delivers excellent weld bead appearance with fine ripple formation—ideal for professionals who demand consistent results.
Welding Positions
✔️ Flat (⎺)
✔️ Horizontal (→)
✔️ Vertical (│)
✔️ Overhead (∩)
-
High mechanical strength with excellent crack resistance
-
Very stable arc in all welding positions
-
Low spatter, easy slag removal
Mechanical Properties
| Property | Value |
|---|---|
| Yield Stress | 460 N/mm² |
| Tensile Strength | 530 N/mm² |
| Elongation (%) | 27% |
| Charpy V-Notch (-20°C) | 100 J |
Chemical Composition (%)
| Element | % |
|---|---|
| Carbon | 0.06 |
| Manganese | 0.80 |
| Silicon | 0.40 |
Classification
AWS A5.1 — E7018
Recommended Current Range (A)
Diameter: 2.6 mm
| Position | Amperage |
|---|---|
| Flat / Horizontal / Vertical | 60–90A |
| Vertical Up / Overhead | 50–80A |
Diameter: 3.2 mm
| Position | Amperage |
|---|---|
| Flat / Horizontal / Vertical | 90–130A |
| Vertical Up / Overhead | 85–125A |
Diameter: 4.0 mm
| Position | Amperage |
|---|---|
| Flat / Horizontal / Vertical | 140–180A |
| Vertical Up / Overhead | 120–140A |
Diameter: 5.0 mm
| Position | Amperage |
|---|---|
| Flat / Horizontal / Vertical | 160–230A |
| Vertical Up / Overhead | 170–270A |
